Boortorens Te Koop

12 ft L x 12 ft W Substructure • Stairs • Safety Rails • Schramm Drawworks • 325 kW Generator • 250 kW Generator • Schaffer/Townsend 9 in 21000 psi Blowout Preventer • Triplex Pump • (1) Shale Shakers***Please see the specification documents below.***

3 in Standpipe & Manifold • Hydraulic-Explorer 2 3000 496 kW Drawworks • Marathon MagnaMax 305 kW Generator • Control Technology 9 in 21000 psi Blowout Preventer • Triplex Pump • (1) Shale Shakers • Foremost Pipe Arm Catwalk • Rig Moves Quickly • Small Footprint • Capable of Operating Independently Without the Need for a Third Party Coring Unit

HANJIN D&B Generator • AC Powered

6.6 m L x • ( 1 ) Crown Sheave Cluster • 80 mm Standpipe & Manifold • Deutz 96 kW Generator • 2010 Fassi Knuckle F22A22 Crane • 3 Stage Boom • A261124

Seller's Info:•National 1625 DE (3000HP) • (3) GE 752 (1 •000) motors • Baylor 7838 aux brake • 1 •420 •000# w/14 Lines•1 •250 •000 lb w/12 Lines • 1 •075 •000 w/10 Lines • SJPetro 37 1/2" rotary/hyd driven rotary table•Cont. Emsco 650 Ton - 1 ½" • NOV TDS-11SA 500 Ton top drive • Varco ST-80C•Forum hyd catwalk • IAT rotating mouse hole • (4) Cat 3512 engines• 18 •000 gal diesel tank • (4) Kato 1365kw gen sets • (4) Omron gen set bays/(4) SCR bays•1 •400 •000 lb hook load • 33 •000' 5"/30 •000' 5 1/2" racking capacity • box on box 30' • 22' clear height•1 •400 •000 lb casing/800 •000 lb setback • 150'x40' x • y axis pad capacity•6 station/180 gal accumulator • 10 •000 psi choke manifold • Poor Boy Degasser•(3) HH-1600 mud pumps•7 •500 lb WP PSI fluid ends & delivery sys•(3) 6x5x14 60HP charging pumps•(3) Brandt King Cobra linear motion shale shakers• Veristic walking sys (optional)

Stairs • Safety Rails • 750000 lb Static Hook Load Capacity Mast • ( 6 ) Crown Sheave Cluster • 5 in Standpipe & Manifold • Letourneau 1 Drum Drawworks • Electric Brake • Omron Driller's Control Console • Split Master Bushing • Hydraulic Elevator • Kato 1950 kVA Generator • Kato 1950 kVA Generator • Kato 1950 kVA Generator • SCR • Air Conditioned • Sullivan Palatek Air Compressor • Sullivan Palatek Air Compressor • Oil Works Air Compressor • Advanced Pressure Blowout Preventer • Centrifugal Pump • (2) Shale Shakers • Desanders • Desilters

Open Operator Station • Yanmar 4 Cylinder Diesel Engine • 500 mm Rubber Tracks • 6800 mm Mast • A267619

Line Size 1 1/4 in • O.D. Sheave 44 in • Total Weight 8390 lbs

Line Size 1 1/4 in • O.D. Sheave 44 in • Total Weight 8390 lbs

- Engine: Hyundai; Power - 420PS/2000RPM; Cooling System - Water Cooling; - Drill Head Section: Reduction - Super gear - 5.1 to 1; Max. RPM - 1st 0-150rpm; 2nd 0-200rpm; Max. Torque - 1st 2600kg-M; 2nd 1300kg-M; - Feed System Head travel 1st: 11M; 2nd: Up- 1.4M • Down- 1.8M Pull-up capacity 120ton Pull-down capacity 9ton - Main Feed Winch Spool capacity 30M of 19㎜ cable Line pull 17 tons - Sub Feed Winch Spool capacity 25M of 16㎜ cable Line pull 9 tons - Winch Spool capacity 27M of 12㎜ cable Line pull 3 tons - Main Hydraulic System 3 pump open loop system Pump discharge rate H3V280DT (P1:280cc • P2:280cc) +Gear Pump(P3:10cc) - Sub Hydraulic System 4 pump open loop system - Pump discharge rate H3V63DT (P1:63cc • P2:63cc) +HSF30D (P3:30cc • P4:30cc) - Working Table Max. Casing diameter 12" Lod Handler Tilting Degree 90° Lod Handler Clamp Size Max 127mm - Crawler Base Crawler type Solar 220 (Motor : Solar 220) Ground pressure 0.5㎏/㎠

2 ft 0 in L x • Four-speed transmission • Cable drill • 496 m of NQ drill rods • Water pump and pump shack • 500gal diesel fuel tank with pump.

Enclosed Cab • Air Conditioner
